The Simpson Strong-Tie Twin Post Cap in Z-Max galvanized finish is designed for 6x6 lumber connections. These connectors are always installed in pairs and connect four wood members at right angles, eliminating the need to drive nails into end grain.
- Made with 18-gauge Z-Max galvanized steel for corrosion resistance and durability
- Nails can be added in the triangle holes to increase uplift load capacity
- Minimum installation: twelve 16d HDG nails into beam, eight 16d HDG nails into post
- Maximum installation: fourteen 16d HDG nails into beam, fourteen 16d HDG nails into post
- Stronger than angled nailing or screw fastening
SKU: 43169924
Shop more products by Simpson Strong-Tie.
DETAILS
DESCRIPTION
The Simpson Strong-Tie Twin Post Cap in Z-Max galvanized finish is designed for 6x6 lumber connections. These connectors are always installed in pairs and connect four wood members at right angles, eliminating the need to drive nails into end grain.
- Made with 18-gauge Z-Max galvanized steel for corrosion resistance and durability
- Nails can be added in the triangle holes to increase uplift load capacity
- Minimum installation: twelve 16d HDG nails into beam, eight 16d HDG nails into post
- Maximum installation: fourteen 16d HDG nails into beam, fourteen 16d HDG nails into post
- Stronger than angled nailing or screw fastening
FEATURES
SKU:
43169924
UPC:
044315409202
