Leviton R92-GFTR1-0KW Slim Tamper Resistant Gfci Receptacle, 15 Amp, White

---

DESCRIPTION

Highlights:

• Advanced electronics design provides superior resistance to electrical surges and over-voltages
• Built-in end-of-life indication - if the SmartLockPRO receptacle can no longer provide GFCI protection, it will not reset and no power is supplied to the face or downstream receptacles
• Cover made from impact-resistant nylon for longer life
• Features one piece T trip latch mechanism for efficient operation
• Improved immunity to high-frequency noise reduces nuisance tripping
• Mechanical shutter mechanism prevents access to contacts unless a two-pronged plug is inserted
• SmartLockPRO diagnoses line-load reversal upon installation and will not reset if mis-wired; green LED indicator light alerts installer to line-load reversal
• The SmartLockPRO receptacle automatically tests the GFCI every time the RESET button is pushed, the GFCI will not reset if the GFCI circuit is not functioning properly
• Trip threshold meets or exceeds UL requirements for tripping time

Specifications:

• Voltage: 125 Volt
• Amperage: 15 Amp
• No. of Poles: 2
• Operating Temperature: -35 Degree C to 65 Degree C (-31 Degree F to 149 Degree F)
• No. of Wires: 3
• Applicable Standards: NEMA: WD-6, ANSI: C-73, UL 943: Class A (GFCI), UL 498: File E13399, CSA C22.2 No. 42: File LR-57811, NOM: 057
• Trip Level: 5mA Plus or Minus 1mA
• HP Rating: 1 HP
• Material: Nylon (Face), Polycarbonate (Body), Steel (Strap)
• Termination: Back & Side 20A Feed-Thru
• Flammability Rating: Rated V-2 per UL94
• NEMA Type: 5-15R
• Dielectric Voltage: Withstands 1500V per UL498
• Type: Monochromatic
• Current Interrupting: 2 KA
