Transfer lines, hot oils, compressed air/gases, adhesive dispensing, coolant lines and medical gases.
SKU: 42556452
MFG: 93451
Shop more products by Imperial.
We offer lowest price on Industrial Hoses, save money on large orders with Life and Home.
DETAILS
DESCRIPTION
Highlights:
- Color: Sliver
- Min. Bend Radius: 3"
- Cover Material: 304 Stainless Steel
- Hose I.D.: 1/4"
- Reinforcement Material: 305 Stainless Steel Wire Braid
- Hose O.D.: 3/8"
- System of Measurement: Fractional
- Inner Tube Material: Natural FDA Compliant PTFE
- Temperature Range (Deg F): -100 to +450 deg. F
- Construction meets or exceeds all requirements of SAE 100R14 inner tube or extruded PTFE with stainless steel wire braid outer cover
- Temperature Range: -100° F to 450° F (-73° C to 232° C)
- Steam Service: Maximum for steam is 200 psi at 388° F
- Vacuum Service: 28" of Hg sizes -4 through -10, 12" of Hg size -12
- Hose Inside Diameter: 1/4"
- Hose Outside Diameter: 3/8"
- Maximum Working Pressure at 75° F: 3,000 psi
- Minimum Burst Pressure: 12,000 psi
- Minimum Bend Radius: 3.0"
- Applications: Transfer lines, hot oils, compressed air/gases, adhesive dispensing, coolant lines and medical gases
- Cross Reference: 919-5
Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm
FEATURES
MFR:
93451
SKU:
42556452
Brand:
Imperial
