DESCRIPTION

Highights:

• Pipe Thread: 3/8
• Thread Size: 11/16-20
• Cross Reference: 1269 x 8
• Tube Outside Diameter: 1/2
• Not recommended for steel tubing
• Vibration resistance is excellent
• Polyline® Fittings are easy to assemble, no flaring is necessary
• Weatherhead® PT200 and PT240 plastic tubing requires a plastic sleeve
• Typical Applications: pneumatic instrumentation circuits, lubrication, and cooling lines
• Used with aluminum, copper, or hard plastic tubing (plastic tubing requires a brass sleeve
• Temperature range depends on tubing used: for brass sleeve: -65° F. to 250° F., for plastic sleeve: -40° F. to 150° F
• Pressure: Up to 500 psi depending on tube size. When using plastic tubing, use the working pressure for type used
