Highlights:
- Thread Size: 3/8-24
- Tube Outside Diameter: 1/4
- Cross Reference: 1262 x 4
- Vibration resistance is excellent
- Not recommended for steel tubing
- Polyline® Fittings are easy to assemble, no flaring is necessary
- Weatherhead® PT200 and PT240 plastic tubing requires a plastic sleeve
- Typical Applications: pneumatic instrumentation circuits, lubrication, and cooling lines
- Used with aluminum, copper, or hard plastic tubing (plastic tubing requires a brass sleeve
- Temperature range depends on tubing used: for brass sleeve: -65° F. to 250° F., for plastic sleeve: -40° F. to 150° F
- Pressure: Up to 500 psi depending on tube size. When using plastic tubing, use the working pressure for type used
