"IMPERIAL SUPPLIES" UNION ELBOW
- Inverted Flare Tube Union Elbow Fitting.
- Inverted Flare Tube Fittings conform to ASA, ASME, SAE, and Mil. specifications.
- This short-bodied fitting fits in tighter places than other styles of fittings.
- Particularly well-suited for hydraulic brake systems, fuel equipment, and refrigeration applications.
- Seats and threads are recessed and protected. Short nuts affords very close tube bends.
- Used with copper, brass, aluminum, and steel hydraulic tubing or steel lines that can be flared.
- Working pressures up to 2,000 psi, depending upon tubing being used.
- Excellent vibration resistance.
- Temperature Range: -65° F. to 250° F. at maximum operating pressures.
- Typical Applications: pneumatic instrumentation circuits, lubrication, and cooling lines.
- Tube Outside Diameter: 1/4
- Thread Size: 7/16-24
- Cross Reference: 502 x 4
