Use as an outdoor main breaker load center. This load center is built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers.
SKU: 43105730
MFG: BRP30B200R
Shop more products by Eaton.
DETAILS
DESCRIPTION
Highlights:
- Dimensions : 14-5/16" x 34-1/8" x 5-3/16"
- Voltage : 120/240 VAC
- Amperage : 200 A
- Includes : (5) BR120, (1) BR230 Circuit Breakers
- Interrupt Rating : 25 kA
- Number of Circuits : 40
- Feed Type : Top/Bottom
- BR series
- Rainproof galvanized steel enclosure
- Single phase, 3 wire, insulated/bonded neutral, 30 (1") spaces, 40 poles, 120/240 volt AC
- Main breaker type BW at 25,000 AIC
- Furnished with hub closure plates, hubs and ground bar kit (necessary for sub-feeding) sold separately
- Tin plated aluminum bus bar
- Twin neutral with non-removable cross bus connecting them
- When bonded, unused neutral connections may be used for equipment ground protectors in service entrance application
- #2 - 300 kcmil wire range
- Electrostatic powder coat, baked urethane painted
- Rotate 180 degrees for bottom feed; orientation of main breaker handle consistent with NEC 240-81 requirements because it operates horizontally
- UL Listed
FEATURES
MFR:
BRP30B200R
SKU:
43105730
UPC:
786689059347
Brand:
Eaton
