DESCRIPTION

Highlights:

• Axial-glide system: durable precision - consistent precision over tool life; compact workspace - saves up-to 12 in workspace; glide action - unmatched smoothness of cut
• Expanded cutting capacity: 14 in horizontal capacity (nominal), 6-1/2 in vertical capacity against the fence (base), 6-1/2 in crown capacity against the fence (45 deg spring)
• Upfront bevel controls - all-metal bevel lock lever and range selector located upfront for quick and easy bevel settings without reaching behind the saw
• Square lock quick-release fences: high-precision square lock fence aligns 90 deg to table and requires no adjustment; one-touch lock/unlock to slide fence for added support
• Integrated expanding base extensions: 60% more left-to-right material support than leading competitor - 40 in left to right
• Large easy-to-read uniform bevel and stainless steel miter scales: 52 deg left/60 deg right miter capacity; 47 deg left/47 deg right bevel capacity with marked detents and roof pitch angles
• Adjustable miter detents: detents at 0, 15, 31.6, 22.5, 45, 60 deg right super-accurate and durable design
• Push-button miter detent override - easy-to-access thumb actuated control right up front for fine miter angle adjustment
• Category best 90% dust collection - optimized for cutting 2x material with a vacuum
• Ergonomic ambidextrous trigger handle with soft grip - large form fitting ergonomic handle provides comfort for all-day use
• UL Listed

Specifications:

• Type: Double Bevel, Glide
• Voltage Rating: 120 V
• Amperage Rating: 15 A
• Power Rating: 3 Hp
• Blade Size: 12" Diameter
• Includes: (1) 12 In 60T Blade, (1) Material Clamp, (1) Dust Bag
• Blade Type: 60T Carbide
• Arbor/ Shank Size: 1"
• Speed: 3800 Rpm
• Cutting Capacity: 14"
• Miter Capacity: 0 - 52 Deg Left, 0 - 60 Deg Right
• Bevel Capacity: 48 Deg
• Bevel Stops: 0, 33.9, 45 Deg
• Locking Type: Spindle
• Handle Style: Ergonomic Ambidextrous Trigger
• Overall Depth: 40"
