DETAILS
DESCRIPTION
Highlights:
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis, or in the cab
- Thermoplastic housing and silicone seals (both are temperature rated from -55 degree C to 125 degree C) are used to allow the connector to withstand conditions of extreme temperature and moisture
- Cavities: 3
- Used with Deutsch Receptacle, Catalog ID: 42604354
- Pack of 10
Deutsch DT Series Connector Material Specifications:
- Seals: silicone elastomer
- Housing for Plugs and Receptacles: thermoplastic
- Secondary Locks: thermoplastic
- Contacts: copper alloy, nickel plated, gold optional
Ordering Notes:
- Select Plug or Receptacle
- Select required Secondary Lock
- If needed, select matching Receptacle or Plug
- Select Terminal according to wire gauge
- Use Crimping Tool, Catalog ID: 42604564 or Catalog ID: 42604741 to assure secure durable crimp
